A Huawei Mate 70 RS Ultimate was disassembled to extract the Kirin 9020 | Infinium-tech
Huawei Mate 70 series launches with a mysterious new chipset – Kirin 9020. Huawei hasn’t revealed much about it, so people had to do their own research.
blogger Yang Changshun Repairman Opened up the Huawei Mate 70 RS Ultimate and desoldered the chipset. The carrier board is larger and thicker than previous Kirin 9000 chips, but that doesn’t reveal much about the silicon inside.
Taking out the Kirin 9020 from the Huawei Mate 70 RS Ultimate
From what we know so far, the Kirin 9020 has an 8-core, 12-thread CPU with one 2.5GHz core, three 2.15GHz cores, and four 1.6GHz cores (the last four are single-threaded). The GPU is a Malone 920 running at 840MHz.
Moving away from the chipset, the Mate 70 series apparently uses a material called titanium basalt to improve the phone’s drop resistance. In this you can see drop test bilibili videoAdditionally, Huawei switched to the second generation Kunlun Glass, which has double the drop resistance of the first generation.
through (in Chinese)
